10" Grooved Check Valve Lead Free Fire Protection System
R 46,390.00
Sale price
R 46,390.00
Regular price
R 71,194.00
Shipping calculated at checkout
The 10" Grooved Check Valve Lead Free Fire Protection System is engineered for industrial, commercial, and municipal fire suppression applications to provide reliable backflow prevention while safeguarding potable water supplies. Installed primarily within commercial fire protection piping networks, this valve permits fluid flow in a single direction and positively closes against reverse flow to maintain system integrity during fire events. Optimized for horizontal pipe installation, the valve design reduces pressure drop and promotes efficient flow during system activation.
This component supports compliance with NFPA 13 (standard for the installation of sprinkler systems) and NFPA 25 (standard for the inspection, testing, and maintenance of water-based fire protection systems). Utilizing this UL-certified and FM-approved valve ensures adherence to jurisdictional mandates for backflow prevention, potable water protection under NSF/ANSI 372 standards, and mandatory periodic inspection protocols.
Key Features & Construction
- Lead-Free Bronze Body: Constructed from a corrosion-resistant lead-free bronze alloy meeting NSF/ANSI 372 standards to eliminate lead contamination risks in potable water networks.
- Grooved End Connections: Features 10" grooved ends compliant with AWWA C606 specifications, enabling rapid mechanical joint installation and simplified maintenance compared to flanged assemblies.
- Precision Internals: Equipped with stainless steel springs and resilient elastomer seat seals that ensure positive closure and prevent leakage across varying flow and pressure conditions.
- Working Pressure Rating: Rated for a maximum working pressure of 175 PSI (12.1 bar) to accommodate standard municipal and commercial fire suppression pressures.
- Horizontal Orientation: Designed specifically for horizontal piping configurations to minimize flow restriction and pressure loss.
Technical Specifications & Compliance Table
| Technical Parameter | Specification |
|---|---|
| Manufacturer / Brand | Nibco Inc. |
| Model / Series Number / SIN | 10" Grooved Check Valve Lead Free Fire Protection System |
| Connection / Thread Size & Type | 10" Grooved Ends (AWWA C606) |
| Pressure Rating (WWP) | 175 PSI (12.1 bar) Max Working Pressure |
| K-Factor | N/A |
| Temperature Rating / Response Type | N/A |
| Material / Body Construction | Lead-Free Bronze Body, Stainless Steel Springs, Elastomer Seat Seals |
| Agency Listings & Approvals | UL Listed (UL 321), FM Approved, NSF/ANSI 372 Certified |
| Applicable NFPA Standards | NFPA 13, NFPA 25 |
Contractors and facility managers must verify all local Authority Having Jurisdiction (AHJ) requirements and review the manufacturer's engineering data sheets prior to beginning installation or system modification.
Documentation: Download Manufacturer Technical Data & Cut Sheet (PDF)
