1/8" FNPT Stainless Steel Piston Spring Check Valve
R 681.00
Sale price
R 681.00
Regular price
Skip to product information
Request for Tax Exemption
Request a Quote
1/8" FNPT Stainless Steel Piston Spring Check Valve
R 681.00
Sale price
R 681.00
Regular price
Shipping calculated at checkout
ZORO SELECT Series 215 piston spring check valve is an inline, single-flow valve for air and fluid service. It is configured for one-direction flow applications with a spring-loaded stainless steel piston and 1 psi cracking pressure. The stainless steel body has 1/8 in FNPT x FNPT connections for compatible piping applications.
Key Features:
- Valve type: Piston spring check valve with inline piston design
- Body material: Stainless steel
- Check mechanism, seat, and spring material: Stainless steel
- Seal material: Buna-N
- Connection type: 1/8 in FNPT x FNPT with female connections on both sides
- Cracking pressure: 1 psi
- Maximum operating pressure: 500 psi
- Operating temperature range: -20 Degrees F to 180 Degrees F
- Media: Air, fluids
- Mounting orientation: Horizontal, vertical
- Flow coefficient (Cv): 0.6
- Full flow: Yes
- Overall length: 1.38 in
- Standards: UL, UR
- Ship Pack Height: 0.6
- Ship Pack Length: 1.4
- Ship Pack Width: 0.6
If you qualify for sales tax exemption, please submit your exemption details and supporting documents. Our team will review your request, and once approved, your account will be updated to receive tax-exempt checkout on eligible purchases.
If you can't find the product you're looking for, send a quote request below.
